Catalytic Converter Description and Operation
Description
The catalytic converter of the gasoline engine is a three way
catalyst. It oxidizes carbon monoxide and hydrocarbons (HC), and
separates oxygen from the oxides of nitrogen (NOx). ...
Valve Body Components and Components Location
Components Location
1. PCV adjust screw2. Solenoid valve3. Oil temperature sensor4. Accumulator5. Low & reverse brake(LR/B) pressure flow hole6. Under drive brake (UD/B) pressure flow hole
...
Driver Airbag (DAB) Module and Clock Spring Description and Operation
Description
Driver Airbag (DAB) is installed in the steering wheel and
electrically connected to SRSCM via the clock spring. It protects the
driver by deploying the airbag when frontal crash oc ...
